Customizable O2 Portable Gas Detector With EN/IEC 60079-0 Impact Test

Name: Customizable O2 Portable Gas Detector With ENIEC 600790 Impact Test
Brand: ALPHASENSE
Price: 32.00 USD

Buy cheap Customizable O2 Portable Gas Detector With EN/IEC 60079-0 Impact Test product

Place of Origin : Jiangsu, China

Brand Name : ALPHASENSE

Certification : ATEX, UL

Packaging Details : carton

Supply Ability : 1000 Set/Sets per Year

Price : $32.00/sets >=1 sets

Warranty : 1 year

Type : gas sensor

Customized support : OEM

Gas type : O2 0-25%VOL

Principle : ELECTROCHEMICAL

CE standard : EN/IEC 60079-0 impact test

HS code : 9027100090

Weight : 0.3g

Output Signal : 0.10 ± 0.02 mA in Air

Response Time (T90) : <15 Seconds

Operating Temperature Range : -20°C to +50°C

Port : FOB Nanjing / FOB Shanghai

Stock : 1PC

MOQ : 1PC

Contact Now

Honeywell Ammonia Nh3 Gas Sensor for Gas Detector

Customizable O2 Portable Gas Detector With EN/IEC 60079-0 Impact Test

>>> Product description

After the analog signal output by the oxygen electrochemical sensor is amplified by the module, it is sent into the ADC acquisition port of STM32 single-chip microcomputer. After the filtration operation inside the STM32 single-chip microcomputer, the oxygen concentration in the air is calculated and then output from the serial port. The module is compatible with 40XV,Me2-O2,AAY80-390R and other electrochemical probes. Module uses high precision rail-to-rail amplifier AD86XX amplifier circuit, integrated ARM Cortex M0 32-bit CPU,12-bit ADC sampling, serial port output oxygen concentration, can be calibrated through the serial port output value,baud rate 115200.

Electrochemical gas sensor is based on the principle of electochemistry,using the measured gas on the sensor working electrode and electrode corresponding REDOX reaction and release charge,through the external circuit to form a current, current size is proportional to the concentration of gas,so as to achieve the quantitative measurement of the target gas.

Applicable

It can be used in automobile, laboratory,coal mine, steel, petrochemical,medical and other measuring environments.
